Telwin Multiprocess Welding Machine, 816190, Electromig 450 Synergic, 230/400V
Return or exchange within 30 days of delivery
Sign in to see your account price and place orders.
Specifications
| SV Code | 457849136728 |
| Brand | Telwin |
| Category | Multiprocess Welding Machines |
| Unit | Piece |
| Brand Origin (not manufacture) | Italy |
| Color | Red and Black |
| Voltage | 230/400V |
| Ingress Protection | IP23 |
| Certification | CE, EAC |
| Accessories Included | Feed Roll 4R 0,8FE-1,0FE "P-K", Feed Roll 4R 1,2FE-1,6FE "P-K", 35 MMQ Cable Work Clamp DX50, MT36 MIG Torch |
| Measuring Current Range - DC | 200/270ADC |
| Phase | 3 |
| Welding Current Range Amps | 20-320/20-400A |
| Power Factor | 0.9 |
| Maximum Voltage(no load) | 106/73V |
| Efficiency | 0.89 |
| Frequency | 50/60 Hz |
| Delivery | On our shelf and ready to go out today. |
Description
MIG-MAG/FLUX/BRAZING/MMA and TIG DC-Lift multiprocess inverter welding machine controlled by a microprocessor, with 4-roller wire feeder. Flexible use with various welded materials (steel, stainless steel, aluminium) or brazed materials (galvanised sheet metal). Wide variety of application fields, from industry to maintenance, installation to bodywork activities. Synergic adjustment makes the product simple to use. The Made in Telwin ATC technology makes it easy to achieve excellent standards of welding on thin materials thanks to state-of-the-art control of the arc.
Features
- Possibility of creating, saving and retrieving customised welding programs
- MIG-MAG adjustments: wire up slope, electronic reactance, wire burn-back time, post gas
- 2/4 time operation selection, Bi-Level, spot, inch and mm material thicknesses
- Adjustments in MMA: hot start, arc force, anti-stick
- Protections: thermostatic, overvoltage, undervoltage, overcurrent, engine driven generator (+/-15%)
- Complete with MIG-MAG torch, cable and earth clamp
- Max. Absorbed Current: 33/25A
- Absorbed Current at 60%: 17/15A
- Max. Absorbed Power: 12.6/16.5 kW
- Absorbed Power at 60%: 6.4/9.4 kW
- Steel Welding Wire Diameter: 0.6-2mm
- Inox Welding Wire Diameter: 0.8-2mm
- Aluminium Welding Wire Diameter: 0.8-1.6mm
- Flux Corded Welding Wire Diameter: 1-2mm
- Brazing Wire Diameter: 0.8-1.2mm
