Phoenix Contact Thermoelectric Voltage Terminal Block, 3100063, MTKD-NICR/NI EX, 400V, 1A, 0.2-4 SQ.MM

Name: Phoenix Contact Thermoelectric Voltage Terminal Block, 3100063, MTKD-NICR/NI EX, 400V, 1A, 0.2-4 SQ.MM
Brand: Phoenix Contact
SKU: phoenixcontact-3100063
Price: 45.00 AED
Availability: PreOrder

SV Code: 711167441615

AED 99.00/ Piece

Price includes VATMore Details

Available in 7 working days

Return or exchange within 30 days of delivery

Fast UAE delivery

Genuine & warranty

Bulk quotes

Specifications

SV Code	711167441615
Brand	Phoenix Contact
Category	Terminal Blocks
Unit	Piece
Article Number	85369010
Color	Grey
Voltage	400 VAC
Amps	1 A
Length	46.2 mm
Width	10.4 mm
Height	47.4 mm
Housing Material	Polyamide
Coverage Area	0.2-4 sq.mm
Number of Connections	4
Number of Positions	2
Connection	Screw
Mounting Type	DIN Rail
Wire Size	24 AWG to 12 AWG
Operating Temperature	- 60 to 85 Deg. C
Delivery	Not on the shelf right now; 7 working days to source and deliver.

Description

The Phoenix Contact Thermoelectric Voltage Terminal Block (model 3100063, MTKD-NICR/NI EX) is a specialized terminal block designed for use with thermocouples.

Features

These special terminal blocks are used to extend thermocouple equalizing conductors in corresponding measuring circuits
This ensures that no false thermoelectric voltages occur at the junctions of the thermocouple/terminal block/compensating line and that the basic values in accordance with EN 60584/DIN EN 60584 are observed
The equalizing conductors are made from materials which, up to temperatures of 200°C, have the same thermal characteristics as the corresponding thermocouples
