Pce Gloss Meter, IGM-60, 3.5 Inch TFT Display, 0 to 300 GU Measuring Range
Return or exchange within 30 days of delivery
Sign in to see your account price and place orders.
Specifications
| SV Code | 635761317115 |
| Brand | Pce |
| Category | Gloss Meters |
| Unit | Piece |
| Color | Black |
| Light Source | D65 |
| Display Type | TFT |
| Battery Type | Li-ion Rechargeable Battery |
| Measuring Range | 0 to 300 GU |
| Accuracy | +/-1.2 % |
| Battery Capacity | 3200 mAh |
| Language | English, Chinese |
| Display Size | 3.5 Inch |
| Interface Type | USB/RS-232 |
| Operating Temperature | 0 to 40 Deg.C |
| Storage Temperature | - 20 to 50 Deg.C |
| Relative Humidity | < 85 Percent (Non-Condensing) |
| Time | 0.5 sec |
| Delivery | On our shelf and ready to go out today. |
Description
The Gloss Meter is an optical measuring instrument with a measuring geometry of 60 deg. The surface is analyzed by the gloss meter and then the result is shown. Every surface has the characteristic to reflect light. This feature is used by the gloss meter to send light onto the surface. This happens when the gloss meter PCE-IGM 60 is at an angle of 60 deg. A large part of the transmitted light penetrates the surface and the remaining light particles are reflected from the surface. Then the gloss meter calculates which gloss value the surface has, by the light that is reflected. The measured values thus obtained can be stored directly on the gloss meter. Using the supplied software, it is possible to read out the data at a later time on the computer and analyze it. The fact that the glossmeter has a measuring range up to 2000 measurement points ensures that the majority of surfaces can be measured with the gloss meter.
- Measurement geometry: 60 Deg
- Fast measurement time
- Internal data memory
- Including evaluation sofware
- Wavelength: 400-700nm
Features
- Measurement geometry: 60 Deg
- Fast measurement time
- Internal data memory
- Including evaluation sofware
- Wavelength: 400-700nm
- Measuring surface: 9 x 15mm
- Repeatability: Measuring range 10 to 100 GU: ±0.2 GU
- Reproducibility: Measuring range 10 to 100 GU: ±0.5 GU
- Chromaticity: Corresponds to CIE 1931 (2 deg) under a CIE C - light source
- Standards: ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457
