Hioki AC/DC Digital Multimeter, DT4261, 1000V
381544635932 · Hioki

Hioki AC/DC Digital Multimeter, DT4261, 1000V

SV Code: 381544635932
Model No.: DT4261
AED 1,128.00AED 1,350.00-16%/ Piece
Price includes VATMore Details
In stock — ships today

Return or exchange within 30 days of delivery

Sign in to see your account price and place orders.

Fast UAE delivery
Genuine & warranty
Bulk quotes

Specifications

SV Code381544635932
BrandHioki
CategoryDigital Multimeters
UnitPiece
YouTube Embed URLhttps://youtu.be/Y2RTOX06A1s
Warranty3 yr.
Brand Origin (not manufacture)Japan
Voltage99.99Hz- 99.99kHz
Display TypeLCD
CertificationCE
Battery TypeLR6 Alkaline AA
Power Source TypeBattery
Operating Time130 hrs
Measuring Voltage Range - DC600mV to 1000V
Measuring Voltage Range - AC6-1000 VAC
Measuring Current Range - DC600mA to 10A
Measuring Current Range - AC600mA to 10A
Measuring Capacitance Range1 to 10 mF
Measuring Resistance Range600 Ohm to 60 Mohm
Measuring Frequency Range40 Hz to 1 kHz
Width87 mm
Height185 mm
Depth47 mm
AC Voltage Accuracy40-500 Hz
DC Voltage Accuracy+/-0.15%
Number Of Battery3
Refresh Rate5 times/sec
DeliveryOn our shelf and ready to go out today.

Description

Hioki mid-range DMM, the DT4261, is an exceptional support tool with multifaceted functionality designed to help analyse a variety of issues and boost work efficiency.

  • Helping personnel analyse issues in the field
  • Boost work efficiency with digitalization (Excel Direct Input Function)
  • Ensuring safety by preventing erroneous test lead insertion (terminal shutters)
  • Stop worrying about losing test lead caps
  • Excellent dust and water resistance (compliant with the IP54 international standard)

    • DC + AC Voltage range

  • Measuring Range: 6.000V to 1000V, 4 ranges
  • Frequency Characteristics: DC, 40 Hz to 1 kHz
  • Basic Accuracy DC, 40 Hz - 500 Hz: +/-1.0% rdg. +/-13 digit. (True RMS, crest factor 3 or less)

    • LoZ V

  • Measuring Range: 600.0V, 1 range
  • Frequency Characteristics: DC, 40 Hz to 1 kHz
  • Basic Accuracy DC, 40 Hz - 500 Hz: +/-1.0% rdg. +/-13 digit. (True RMS, crest factor 3 or less)
  • DC Current Basic Accuracy: +/-0.5% rdg. +/-3 digit.
  • AC Current Basic Accuracy 40 Hz-500 Hz: +/-1.4% rdg. +/-3 digit. (True RMS, crest factor 3 or less)
  • AC Current Frequency Characteristics: 40 Hz to 1 kHz

    • AC Current range (use with Clamp on probes)

  • Measuring Range: 10A to 1000A, 7 ranges
  • Basic Accuracy 40 Hz-500 Hz: Add the Clamp on probe accuracy to +/-0.9% rdg. +/-3 digit.

    • Continuity Check

  • Continuity threshold ON : 25 Ohm
  • Continuity threshold OFF : 245 Ohm
  • Response time: 0.5 ms or more

    • Diode Test

  • Open Terminal Voltage: 2.0V or less
  • Testing Current: 0.2mA or less
  • Threshold of Forward Voltage: 0.15V to 1.8V
  • Current Frequency Range: 99.99 Hz to 9.999 kHz, 3 ranges
